Development Kits
Altera and Partner Development Kits
Product and Vendor Name
MAX II/MAX IIZ
Development Kit
System Level Solutions
MAX V CPLD
Development Kit
Altera
CoreCommander
Development Kit
System Level Solutions
Cyclone III LS FPGA
Development Kit
Altera
HSMC Prototyping Board
Bitec
ProcPAK II
GiDEL
Device
MAX II
EPM240
EPM240Z
MAX V 5M570Z
Cyclone III
EP3C25F256C8
Cyclone III LS
EP3CLS200F780C7N
Daughtercard
Cyclone II
EP2C35
Description
This board provides a hardware platform for designing and developing simple and
low-end systems based on Altera MAX II/MAX IIZ devices. The board features a MAX II/
MAX IIZ EPM240T100Cx/EPM240ZM100Cx device with 240 LEs and 8,192 bits of user
flash memory (UFM). The board also supports vertical migration into EPM570T100Cx
devices with 570 LEs and 8,192 bits of UFM.
This low-cost platform will help you quickly begin developing low-cost, low-power
CPLD designs. Use this kit as a stand-alone board or combined with a wide variety of
daughtercards that are available from third parties.
This kit features the Altera Cyclone III FPGA that provides more than enough room for
almost any embedded design. This flexible board comes with a suite of SLS IP Cores,
drivers, and application software. Delivered as a complete package, this kit ensures
quick and easy implementation of industry-leading cores with reduced risk, at a very
low cost.
This kit combines a high-density, low-power Cyclone III LS FPGA with a complete suite
of security features implemented at the silicon, software, and IP levels. These security
features provide passive and active protection of your IP from tampering, reverse
engineering, and counterfeiting. It uses the EP3CLS200 FPGA — 200K LEs at less than
0.25 W static power.
This board provides a solution for prototyping circuits and testing them together with
the latest Altera FPGA development kits. This board provides access to the complete set
of HSMC signals via a footprint of standard 0.1” pitch headers. The HSMC power pins
are accessed via fuses for added security. The main prototype matrix comprises a 0.1”
grid interleaved with +3.3 V and GND access points. Footprints for commonly used 25-
way and 9-way D-type connectors are included on the board.
ProcPAK II development kit is based on Altera’s Stratix II FPGA platform. The
development kit greatly improves time to market. There is no need to design the board,
the PCI driver, or the application driver layer, define board constraints, design memory
controller, and write environment FPGA code. This kit enables designers to focus on
their proprietary value-added design instead of spending their valuable effort to
recreate standard design components. With ProcMultiPort innovative memory
controller, the generated HDL code enables high-speed, easy-to-use parallel access to
large memories.
Altera Product Catalog
?
2013
?
www.altera.com
81
